PCB Design Mastery: From Zero to Pro in 5 Hours Using KiCad is a laser-focused course that teaches you to design professional 1-2 layer printed circuit boards from schematic to manufacturing files. Perfect for beginners and intermediate users, this training eliminates all fabrication/soldering content to concentrate exclusively on what matters most – creating clean, manufacturable PCB layouts in KiCad.
You’ll master essential skills through practical projects (gate driver and capacitive switch):
Schematic capture and component selection
- Intelligent board layout strategies for THT and SMD components
- Design rule checking and error prevention
- Gerber/drill file generation for manufacturing
- electronics symbol editor for non-common components
- Footprint assignment editor and assignment for any needed component
The curriculum features real-world projects including:
- An Arduino-compatible shield with mixed THT/SMD components
- gate drivers circuit for general power electronics
- ESP 32 based SMD circuit
What makes this course unique:
- 100% focused on 1-2 layer design – no confusing 4+ layer content.
- Zero fabrication/soldering detours – pure PCB layout training
- Manufacturing-ready outputs accepted by any fab house
- Custom KiCad libraries with pre-verified footprints
- Design-for-manufacturing (DFM) principles from lesson one
